Power supply: AC100-240V±10% 50/60Hz
Power consumption: 800W
Light source：OSRAM 461W
Color temperature: 8500K
Bulb life time：1500h
DMX channel: 24CH
Signal input: standard three-pin / five-pin signal socket input and output
Light bulb system: The design of the remote bulb control system can remotely control the light bulb on and off through the controller, effectively extending the life of the bulb.
Display: LCD display, touch screen + button control, the operation process is quite humanized and convenient, built-in Chinese and English display interface switching,intelligent 180° flip upside down.
Operation page: Built-in multiple pages, itemized design function. The function mode can be customized according to the requirements of the use scenario, with password lock protection.
Intelligent display: Built-in bulb usage time record, you can check the bulb usage at any time, built-in light body temperature display to guide the correct application
Control mode: DMX512, Auto, master-slave, voice-activated
Strobe: double chip strobe, strobe speed 0.5 - 9 times / second
Color wheel: 13 color + white light, with rainbow effect.
Gobo wheel: Fixed gobo 15+ white light, with jitter and water flow effect
Rotate gobo wheel: 6 glass gobos, can clockwise and anti clockwise rotation
Effect plate: clockwise and anti clockwise flow effect plate
Prism: row prism + 8 prism.
Rainbow plate: A rainbow plate with 6 colors, can create gorgeous rainbow effect.
Focusing: high-quality condenser lens, super smooth smooth automatic focus adjustment.
CMY: CMY plate
CTO: color temperature gradient
RDM function: can automatically modify the address code through the DMX cable, detect light failures, and update the program version for intelligent control.
Fan protection: automatic blowout protection for fan failure.
Fan speed regulation: Before turning on the light, run it at a low speed. When the light is turned off at half power, the fan speed also decreases accordingly.
Strobe: Strobe speed is up to 13 times / sceond, and random strobe can be selected.
Dimming: 0-100% linear dimming.
Atomization: 0-100% uniform soft light atomization effect
Pan: 540 °, 16 Bit
Tilt: 232 °, 16 Bit
Automatic error correction: photoelectric reset system is used for horizontal and vertical.
Automatically retrieve and reset if an error occurs.
Appearance material: injection molding with high temperature resistant fireproof engineering plastic.
Protection rate: IP20
Working environment:  -20℃-40℃
Dimension size: 292x390x677mm
Packing size: 530x490x655mm
N.W: 28.5 kg
G.W: 31.4 kg
